PMMP40L Integrated DC Servo Motor 42mm CANopen 3000RPM 100W 0.3Nm 24V Drive & 17-bit Absolute Encoder Waterproof IP65
- Part Number: PMMP4010B-CANopen-L
- Lead Time: In Stock
- Unit Price: US $249.00
- *Ship from China
The order will be shipped out in 24-72 hours if the items are in stock. Please feel free to contact us for more discounts if the order is over 999USD.
The PMMP40L series integrated low-voltage servo motor is a servo enginer independently developed by NIMOTION. Based on the concept of highly integrated development, this intelligent servo motor integrates a permanent magnet synchronous motor, a magnetic encoder, a servo drive controller, and digital I/O into a single unit. It supports CANopen and RS485 bus control and features a compact design with simple wiring. We hope that our product, with its superior performance, excellent quality, and outstanding cost-effectiveness, will help you achieve the motion control you desire.
Specification
- Manufacturer Part Number: PMMP4010B-CANopen-L
- Rated Torque: 0.3Nm
- Rated Voltage: 24V DC
- Rated Current: 6.5A
- Encoder Type: 17-bit Absolute
- Modbus Mode: CANopen
- Frame Size: 42x42mm
- Body Length: 67.7mm
- Shaft Diameter: Φ8m
- Shaft Length: 25mm
- Keyway Length:14mm
- IP Rating: IP65
- Weight: 0.43kg
Contact Us
| Product Details | |
| Model Number | PMMP4010B-CANopen-L |
| Product Type | Integrated Servo Motor |
| Lead Time | in stock |
| Electrical Specification | |
| Rated Torque(Nm) | 0.3 |
| Rated Power(W) | 1000 |
| Rated Voltage(VDC) | 24 |
| Rated Speed(RPM) | 3000 |
| Drive Integrated | Yes |
| Modbus Type | CANopen |
| Encoder Feedback | Yes |
| Encoder Type | Absolute |
| Physical Specification | |
| Frame Size(mm) | 42x42 |
| Body Length(mm) | 67.7 |
| Shaft Diameter(mm) | 8 |
| Shaft Length(mm) | 25 |
| Weight(KG) | 0.43 |
