NEMA 8 Geared Stepper Motor L=38mm 0.6A with Reduction Ratio 20:1 High Precision Planetary Gearbox
- Part Number: 20HS38-0604S-KGS20
- Lead Time: One Week
- Unit Price: $50.00
- *Ship from China
The order will be shipped out in 24-72 hours if the items are in stock. Please feel free to contact us for more discounts if the order is over 999USD.
This geared NEMA 8 stepper motor has 38mm body and 0.6A rated current, integrated with one high-precision planetary gearbox of 20:1 gear ratio. It's an ideal solution to the applications that require limited space but low speed or high torque.
Motor Specification
- Part Number: 20HS38-0604S-KGS20
- Step Angle: 1.8deg w/o gearbox
- Bipolar/Unipolar: Bipolar
- Holding Torque: 0.04Nm w/o gearbox
- Rated Current/phase: 0.6A
- Driving Voltage: 12-24V
- Frame Size: 20x20mm
- Motor Length: 38mm
- Number of Leads: 4
- Lead Length: 300mm
Gearbox Specification
- Gearbox Type: Planetary
- Gear Ratio: 20:1
- Gearbox Efficiency: 94%
- Backlash at No-load: <=20arcmin
- Gearbox Length: 48mm
- Shaft Diameter: Φ6mm
- Shaft Length: 19.5mm
- D-cut Length: 15mm
Contact Us
| Motor Specification | |
| Step Angle(°) | 1.8 |
| Bipolar/Unipolar | Bipolar |
| Holding Torque(Nm) | 0.04 |
| Holding Torque(oz.in) | 5.68 |
| Rated Current(A) | 0.6 |
| Frame Size(mm) | 20x20 |
| Body Length(mm) | 38 |
| Driving Voltage(VDC) | 12-24 |
| Gearbox Specification | |
| Gearbox Type | Planetary |
| Gear Ratio | 20:1 |
| Efficiency | 94% |
| Backlash at No-load | 20arcmin |
| Gearbox Length(mm) | 48 |
| Shaft Diameter(mm) | 6 |
| Shaft Length(mm) | 19.5 |
L1=38mm, L2=48mm
Motor 4 Wires Connection: A+ Black, A- Green; B+ Red, B- Blue
