Integrated Stepper Motor NEMA 17 Closed Loop 0.59Nm/83.78oz.in 12-40VDC Drive & 1000PPR Encoder
- Part Number: 42HS48-200E-YT
- Lead Time: In Stock
- Unit Price: US $29.90
- Sales: 18
- *Ship from China
The order will be shipped out in 24-72 hours if the items are in stock. Please feel free to contact us for more discounts if the order is over 999USD.
Integrated Stepper Motor NEMA 17 Closed Loop 0.59Nm/83.78oz.in 12-40V Drive & 1000PPR Encoder
Electrical Specification
- Manufacturer Part Number: 42HS48-200E-YT
- Step Angle: 1.8deg
- Holding Torque: 0.59Nm/83.78oz.in
- Drive Input Voltage: 12-40VDC
- Drive Output PCurrent: 0.2-3.2A
- Drive Logic Input Voltage: 5.0V
- Encoder Type: Incremental
- Encoder Resolution: 1000PPR
Physical Specification
- Frame Size: 42x42mm
- Body Length: 71mm
- Shaft Diameter: Φ5mm
- Shaft Length: 24mm
- D-cut Length: 15mm
- Weight: 0.55kg
Contact Us
| Product Details | |
| Model Number | 42HS48-200E-YT |
| Product Type | Integrated Stepper Servo Motor |
| Lead Time | in stock |
| Insulation Class | B |
| Protective Grade | IP20 |
| Electrical Specification | |
| Step Angle(deg.) | 1.8 |
| Bipolar/Unipolar | Bipolar |
| Holding Torque(Nm) | 0.59 |
| Drive Integrated | Yes |
| Control Mode | Pulse |
| Input Voltage(VDC) | 12-40 |
| Encoder Feedback | Yes |
| Encoder Type | Incremental |
| Physical Specification | |
| Frame Size(mm) | 42x42 |
| Body Length(mm) | 71 |
| Shaft Diameter(mm) | 5 |
| Shaft Length(mm) | 24 |
| Weight(KG) | 0.55 |
