12V/24V/36V Φ32mm Coreless Brushless Planetary Gearbox Motor 10-2000 RPM 8.0 N-m
- Brand: Frankhumotor
- Part Number: 32BLC60-PG
- Lead Time: In Stock
- Unit Price: US $199.00
- *Ship from China
This compact electric geared motor combines a diameter 32 mm, coreless brushless DC motor with a high-quality, precision-machined planetary gearbox. With a reduction ratio from 3.8:1 to 664.3:1, it delivers a no-load speed range of 10-2,000 RPM and an output torque of 8.0 N·m. It supports variable-speed control and reversible (CW/CCW) operation. Compared with ordinary brushless DC motors, the coreless motor offers higher efficiency, a higher power-to-weight ratio, faster response, longer service life, and higher torque output. Typical applications include robotics, medical devices, aerospace, and more.
24 VDC Φ32mm Coreless Brushless Planetary Geared Motor
| Reduction Class | Gear Ratio | Rated Voltage | No-load Speed | No-load Current | Rated Speed | Rated Torque | Rated Current | Weight | Total Length |
| (V DC) | RPM | mA | RPM | N-m | A | g | (L+60)(mm) | ||
| 1 | 3.8:1 | 24 | 1847 | 155 | 1561 | 0.17 | 1.73 | 367 | 86.4 |
| 5.1:1 | 1379 | 155 | 1165 | 0.23 | 1.73 | 367 | 86.4 | ||
| 2 | 14.4:1 | 488 | 190 | 412 | 0.59 | 1.77 | 404 | 94 | |
| 19.2:1 | 364 | 190 | 307 | 0.80 | 1.77 | 404 | 94 | ||
| 25.8:1 | 272 | 190 | 229 | 1.07 | 1.77 | 404 | 94 | ||
| 3 | 54.4:1 | 129 | 225 | 109 | 2.03 | 1.80 | 441 | 101.6 | |
| 72.9:1 | 96 | 225 | 81 | 2.71 | 1.80 | 441 | 101.6 | ||
| 97.8:1 | 73 | 225 | 61 | 3.64 | 1.80 | 441 | 101.6 | ||
| 130.9:1 | 53 | 225 | 49 | 4.87 | 1.80 | 441 | 101.6 | ||
| 4 | 206.2:1 | 34 | 255 | 29 | 6.91 | 1.84 | 478 | 109.2 | |
| 276.2:1 | 25 | 255 | 22 | 8.00 | 1.63 | 478 | 109.2 | ||
| 370.1:1 | 19 | 255 | 17 | 8.00 | 1.30 | 478 | 109.2 | ||
| 495.9:1 | 14 | 255 | 13 | 8.00 | 1.03 | 478 | 109.2 | ||
| 664.3:1 | 11 | 255 | 10 | 8.00 | 0.82 | 478 | 109.2 |
8.00 N-m limited by the continuous torque ofthe maximum load ofthe gearbox.
36 VDC Φ32mm Coreless Brushless Planetary Geared Motor
| Reduction Class | Gear Ratio | Rated Voltage | No-load Speed | No-load Current | Rated Speed | Rated Torque | Rated Current | Weight | Total Length |
| (V DC) | RPM | mA | RPM | N-m | A | g | (L+60)(mm) | ||
| 1 | 3.8:1 | 36 | 2771 | 175 | 2536 | 0.15 | 1.73 | 367 | 86.4 |
| 5.1:1 | 2068 | 175 | 1892 | 0.19 | 1.73 | 367 | 86.4 | ||
| 2 | 14.4:1 | 731 | 210 | 669 | 0.49 | 1.77 | 404 | 94 | |
| 19.2:1 | 546 | 210 | 499 | 0.66 | 1.77 | 404 | 94 | ||
| 25.8:1 | 407 | 210 | 373 | 0.88 | 1.77 | 404 | 94 | ||
| 3 | 54.4:1 | 193 | 245 | 177 | 1.68 | 1.80 | 441 | 101.6 | |
| 72.9:1 | 144 | 245 | 132 | 2.25 | 1.80 | 441 | 101.6 | ||
| 97.8:1 | 108 | 245 | 98 | 3.02 | 1.80 | 441 | 101.6 | ||
| 130.9:1 | 80 | 245 | 73 | 4.04 | 1.80 | 441 | 101.6 | ||
| 4 | 206.2:1 | 51 | 275 | 47 | 5.73 | 1.84 | 478 | 109.2 | |
| 276.2:1 | 38 | 275 | 35 | 7.68 | 1.63 | 478 | 109.2 | ||
| 370.1:1 | 28 | 275 | 26 | 8.00 | 1.30 | 478 | 109.2 | ||
| 495.9:1 | 21 | 275 | 20 | 8.00 | 1.03 | 478 | 109.2 | ||
| 664.3:1 | 16 | 275 | 15 | 8.00 | 0.82 | 478 | 109.2 |
8.00 N-m limited by the continuous torque ofthe maximum load ofthe gearbox.
Connection
| P1 | P2 | P3 | P4 | P5 | P6 | P7 | P8 |
| MA | MB | MC | HA | HB | HC | GND | +5V |
| BLU | YEL | WHT | BLU | YEL | WHT | BLK | RED |
Contact Frankhumotor for Datasheet, 3D Step. File, Torque Curve
- Brake
- Cable & Connector
- Encoder
- Gearbox
- Insulation Class
- Output Shaft
- Waterproof Level
