80mm 1000W AC Servo Motor 220V 3.2 N-m 3000RPM 23-Bit Absolute Encoder IP65 Electromagnetic Brake
- Part Number: 80M03230BYS
- Lead Time: In Stock
- Unit Price: US $250.00
- *Ship from China
This 80 mm DC servo motor with electromagnetic brake (80M03230DC48YS) delivers 1000 W of rated power and 3.2 N·m of rated torque (peak torque 6.4 N·m) at 3000 RPM, powered by 48 VDC with a rated current of 25 A. It features a built-in 17-bit multi-turn absolute encoder for high-precision servo control, a 5-pole design, F-class insulation, and IP65 protection, plus an integrated 24 VDC electromagnetic brake for fail-safe position holding on power loss. The brake-equipped version extends the body length to approximately 156 mm within an 80 × 80 mm frame (versus 119 mm for the standard model), with a Φ19 mm shaft (35 mm length) and a weight of roughly 4.0 kg. Its high power output, high-resolution feedback, and power-off braking make it well suited to robotic joints, CNC machining centers, AGV/AMR drive systems, semiconductor handling equipment, medical and laboratory automation, and large-format precision rotary actuators that require reliable position retention on vertical axes or during emergency stops.
80mm 1000W AC Servo Motor 220V 3.2 N-m 3000RPM 23-Bit Absolute Encoder IP65 Electromagnetic Brake
- Manufacturer Part Number: 80M03230BYS
- Rated Power: 1000 W
- Rated Voltage: 220 VAC
- Rated Current: 5.8 A
- Rated Speed: 3000 RPM
- Rated Torque: 3.2 N-m
- Peak Torque: 8.0 N-m
- Peak Current: 15.6 A
- Back EMF Constant: 32.5 V/krpm
- Torque Constant: 0.55 N-m/A
- Electrical Constant: 3.33 Ms
- Line-line Resistance: 1.17 ohms
- Line-line Inductance: 3.9 mH
- Rotor Inertia: 1.55x10-4 kg·m2
- Encoder: 23-Bit Absolute Multi-turn
- Insulation Class: F
- Protection Level: IP65
- Poles Number: 10
- Brake Torque: 4.5 N-m
- Brake Voltage: 24 VDC
- Frame Size: 80x80 mm
- Body Length: 148 mm
- Shaft Diameter: Φ19 mm
- Shaft Length: 35 mm
- Weight: 2.8 kg
Contact Frankhumotor for Datasheet, 3D Step. File, Torque Curve
| Product Details | |
| Model Number | 80M03230BYS |
| Product Type | AC Servo Motor |
| Lead Time | in stock |
| Insulation Class | F |
| Protection Class | IP65 |
| Servo Electrical Specification | |
| Rated Voltage(VAC) | 220 |
| Rated Current(A) | 5.8 |
| Rated Power(W) | 1000 |
| Rated Speed(RPM) | 3000 |
| Rated Torque(N·m) | 3.2 |
| Encoder Type | Absolute |
| Encoder Resolution(PPR) | 23-Bit |
| With Brake | Yes |
| Servo Physical Specification | |
| Frame Size(mm) | 80x80 |
| Body Length(mm) | 148 |
| Shaft Diameter(mm) | 19 |
| Shaft Length(mm) | 35 |
| Weight(KG) | 2.8 |
LA=148mm
