Φ42mm 24V 40W 67RPM 4.61Nm Geared Brushless DC Motor Reduction Ratio 44.69:1 Planetary Gearbox
- Part Number: Z42BLDPN2440-30S-42ZPN44.69
- Lead Time: In Stock
- Unit Price: $95.50
- *Ship from China
The order will be shipped out in 24-72 hours if the items are in stock. Please feel free to contact us for more discounts if the order is over 999USD.
This strong dc geared motor is a 24V diameter Φ42mm round brushless electric engine intagrated with a size 42mm round planetary gearbox. It leads to speed range of 10RPM to 1500RPM and rated torque upto 15Nm. Because of the brushless design, this micro geared motor has higher efficiency, higher power-to-weight ratio, faster response time, longer lifespan, more merits compared to general dc motors. It is widely used in household appliances, office automation, bank equipment, medical devices, intelligent robots, etc.
Specification
- Part Number: Z42BLDPN2440-30S-42ZPN44.69
- Rated Power: 40W
- Rated Current: 2.4A
- Reduction Ratio: 44.69:1
- Rated Torque: 4.61Nm
- Rated Speed: 67RPM
- Insulation Class: B
- Sensor Type: Hall
- Body Length: 139.9mm
- Shaft Diameter: Φ8mm
- Shaft Length: 20mm
- Keyway Length: 16mm
- Weight: 0.8KG
Contact Us
| Brush/Brushless Specification | |
| Motor Type | Brushless |
| Rated Voltage(VDC) | 24 |
| Rated Power(W) | 40 |
| Rated Torque(Nm) | 4.61 |
| Rated Speed(RPM) | 67 |
| Sensor Type | Hall |
| Frame Size(mm) | Φ42 |
| Body Length(mm) | 139.9 |
| Shaft Diameter(mm) | 8 |
| Shaft Length(mm) | 25 |
| Weight(KG) | 0.8 |
L=47.4mm
