Size 42mm NEMA 17 Linear Actuator Non-captive Stepper Motor 48mm Stack 1.68A Lead 8mm Screw Length 200mm
- Part Number: 42HS48-1684N-200L88
- Lead Time: In Stock
- Unit Price: $29.90
- Sales: 19
- *Ship from China
The order will be shipped out in 24-72 hours if the items are in stock. Please feel free to contact us for more discounts if the order is over 999USD.
This non-captive linear actuator electric motor is one size 42mm NEMA 17 linear motion stepper motor with a 48mm body length, 1.8 degree step angle and 1.68A rated current. It is integrated with a 8mm diameter lead screw & lead 8mm per revolution/0.04mm per step, and lead screw length is 200mm.
Electrical Specification
- Part Number: 42HS48-1684N-200L88
- Motor Type: Non-captive Linear Stepper
- Step Angle: 1.8deg
- Bipolar/Unipolar: Bipolar
- Holding Torque: 0.5Nm/71oz.in
- Rated Current/phase: 1.68A
- Driving Voltage: 12-36V
Physical Specification
- Frame Size: 42x42mm
- Motor Length: 48mm
- Lead Screw Length: 200mm
- Lead Screw Diameter: Φ8mm
- Lead Screw/Step: 0.04mm
- Lead Screw/Revolution: 8mm
- Number of Leads: 4
- Lead Length: 500mm
- Weight: 0.4KG
Contact Us
| Motor Specification | |
| Motor Type | Noncaptive Linear Stepper |
| Step Angle(°) | 1.8 |
| Bipolar/Unipolar | Bipolar |
| Holding Torque(Nm) | 0.5 |
| Holding Torque(oz.in) | 71 |
| Rated Current(A) | 1.68 |
| Frame Size(mm) | 42x42 |
| Stack Length(mm) | 48 |
| Driving Voltage(VDC) | 12-36 |
| Lead Screw Specification | |
| Lead Screw Length(mm) | 200 |
| Lead Screw Diameter(mm) | 8 |
| Lead Travel/Revolution(mm) | 8 |
| Lead Travel/Step(mm) | 0.04 |
